The 30 m³ eto gas sterilizer consists of the sterilizer housing, auxiliary equipment (heating and thermal cycling device, vacuum extraction device, dosing and vaporization device, humidification device, sealing device, residual gas processing device), and monitoring and control device.

8.4.1 Closing the eto gas sterilizer Discharge Door 8.4.2 Opening the Loading Door 8.4.3 Loading Sterilization Items Use a forklift

The installation and layout diagram of the ethylene oxide eto sterilizer can be found in Appendix C, Figure C.1. 7.1

12m3 eto sterilizer is ready to send to our customer

3.4.1 eto sterilizer machine Temperature Setting Range
The temperature setting range for the eto sterilizer is: 30 to 70°C

If a leak is detected in the eto sterilizer dosing pipeline during the administration process, immediately close the medication bottle, switch and the dosing valve on the main unit. Turn on the axial fan to ensure proper ventilation, and then proceed with repairs.

Note: Regardless of whether the equipment is in normal operation, malfunction, or maintenance state, if personnel need to enter the

Note 1: The Ethylene Oxide sterilization conditions must be obtained through validation confirmation and should be verified with monitoring and

The temperature of representative areas on the inner surfaces should be measured and recorded using temperature recording instruments that comply with the requirements of Appendix B.

Appearance Inspection: Check the main unit, control rack, and electrical control cabinet for any damage on the surface.
